Outdoor 48 Port ODF Optical Distribution Frame IP66 Mild Steel Fiber Optic Patch Panel

Name: Outdoor 48 Port ODF Optical Distribution Frame IP66 Mild Steel Fiber Optic Patch Panel
Brand: Unique-Tel
Price: 1 USD

Brand Name : Unique-Tel

Model Number : PXJ0916

Certification : CE RoHS

Place of Origin : China

MOQ : 10 pcs

Price : negotiable

Payment Terms : L/C, T/T

Supply Ability : 1000 pcs/month

Delivery Time : within 10 days

Packaging Details : carton package

Uniformity : 1.7dB

Max Capacity : 48 Cores

Adapter Plate : LC FC SC ST

Operating wavelength : 1260-1650nm

Work Temperature : -40°C~+80°C

Atmosphere pressure : 70KPa~106KPa

Dimension : 400*300*95mm

Color : White Gray Black

Material : Cold Rolled Steel

Module Type : Double door open

Contact Now

Outdoor Wall-Mount 48 Port ODF IP66 Mild Steel Fiber Optic Patch Panel Optical Distribution Frame

Overview

Outdoor Wall-Mount 48 Port ODF IP66 Mild Steel Fiber Optic Patch Panel /Optical Distribution Frame is mainly used for connecting the indoor/outdoor optical cables, patch cords and pigtails. It can be wall mounted or pole mounted and provides various accessories to avoid any unexpected damage to the fiber. This types of fiber termination box as distribution box, it is usually used in between wiring closets and equipment for fiber optic cable termination, use and management.

Features

Compliant with ISO (9001, RoHS, UL, Bellcore certification)

Suitable for ribbon and bunchy fiber cables

Fiber splice trays can be installed and changed easily

Small dimension and exquisite and easy for operation

Standard cell structure size, wall mounted patch panel

Application

Widely used in FTTH access network

Telecommunication Networks

CATV Networks

Data Communications Networks

Local Area Networks

Specifications

Module Type	Double door open
Max Capacity	48 Cores
Adapter Plate	LC FC SC ST
Material	Cold Rolled Steel
Color	White Gray Black
Dimension	40030095mm
Atmosphere pressure	70KPa~106KPa
Uniformity	1.7dB
Operating wavelength	1260-1650nm
Work Temperature	-40°C~+80°C

Outdoor 48 Port ODF Optical Distribution Frame IP66 Mild Steel Fiber Optic Patch Panel

Product Tags:

optical fiber distribution frame

power distribution frame

Buy cheap Outdoor 48 Port ODF Optical Distribution Frame IP66 Mild Steel Fiber Optic Patch Panel product

Outdoor 48 Port ODF Optical Distribution Frame IP66 Mild Steel Fiber Optic Patch Panel Images
